Global supply 300w 500w 600w 1000w 1500w 2000w 2500w 3000w 4000w 5000w 6000w 8000w 12V or 24v or 48v Input 110V or 220v AC Output Pure Sine Wave fan Inverter urgent demand of France USA Australia Germany UK Denmark Italy Switzerland Israel India

Global supply 300w 500w 600w 1000w 1500w 2000w 2500w 3000w 4000w 5000w 6000w 8000w 12V or 24v or 48v Input 110V or 220v AC Output Pure Sine Wave fan Inverter urgent demand of France USA Australia Germany UK Denmark Italy Switzerland Israel India

Feature
GB Copper Wire, reducing the line losses.

High quality silicone thermal pad, thermal faster, insulation better.

Oxidation treatment radiator, heat dissipation more better, more safe.

Stainless steel screws, insulation covering played shell and radiator insulation, more safe.

Insulating paper ,make the heat sink and PCB circuit board insulation, avoid leakage, safety protection.

The former driver control panel, PWM signal, the perfect protection, precision patch. Capacitive touch button.

The after driver control panel, Four-layer board sided precision chip

technology, improve the protection of the sine wave signal modulation.

‹

›

2016/1/23

3 张照片 - 查看相册

태양 광 홈 시스템에 대한 론 12V 24V 팬 GPU 태양 블루 M의 PPT 태양 광 충전 컨트롤러와 빅

Victron 12V 24V Fangpusun Blue MPPT solar charge controller for solar home system

태양 광 홈 시스템에 대한 론 12V 24V 팬 GPU 태양 블루 M의 PPT 태양 광 충전 컨트롤러와 빅

Fangpusun charge controller	MPPT 100/30	MPPT 100/50
System voltage	12/24 V Auto Select
Maximum output current	30 A	50 A
Maximum PV power, 12V 1a,b )	440 W (MPPT range 15 V to 80 V )	700 W (MPPT range 15 V to 70 V resp.95V)
Maximum PV power, 24V 1a,b )	880 W (MPPT range 30 V to 80 V )	1400 W (MPPT range 30 V to 70 V resp.95V)
Maximum PV open circuit voltage	100 V
Maximum efficiency	98%
Self-consumption	10 mA
Charge voltage 'absorption '	Default setting:14,4 V / 28.8 V (adjustable)
Charge voltage 'float '	Default setting:13,8 V / 27,6 V(adjustable)
Charge algorithm	multi-stage adaptive
Temperature compensation	-16 mV / °C resp.-32 mV / °C
Protection	Battery reverse polarity (fuse, not user accessible)                         Output short circuit      Over temperature                                    (MPPT 100/50:PV reverse polarity)
Operating temperature	30 to +60°C (full rated output up to 40°C)
Humidity	95%,non-condensing
Data communication port	VE.Direct                                                                        See the data communication white paper on our website
Colour	Blue (RAL 5012)
Terminals(fine / single wire)	13 mm² / AWG 6
Protection category	IP43 (electronic components ), IP22 (connection area)
Weight	1.25kg
Dimensions (X x Y x Z )	130 x 186 x 70 mm
Safety	EN/IEC 62109
1a) If more PV power is connected, the controller will limit input power to 440W resp. 880 W(MPPT 100/50:700W resp. 1400W)                                                                                                            1b) PV voltage must exceed Vbat + 5V for the controller to start. T hereafter minimum PV voltage is Vbat + 1V

16 LED Solar Power Motion Sensor Garden Security Lamp Outdoor Waterproof Light

16 LED Solar Power Motion Sensor Garden Security Lamp Outdoor Waterproof Light

Retail Package Includes:
• 1 x Solar Wall Lamp w/ motion sensor
• 2 x Expansion pillar-hinge
• 2 x Screw
• 1 x Pin
• 1x color box
Overview:
The Propel Solar Motion Sensor LED Light can illuminate your home, yard, driveway, patio and anywhere in which getting solar energy. The motion-sensing light is triggered when someone or something enters within 1-3 meters range in a 120 degree sensing angle.

Great as an intruder deterrent, or used simply to light up your path after you park your car

Product Highlights:
• Powerful Environmentally friendly 16 LED Solar Outdoor LED Light w/ Life Span of 50,000 hours
• Light instantly turns on when it detects motion within 10ft
• Rugged construction that is Waterproof, heatproof and durable enough to last for years
• No batteries, no cables, & easy to install
• Sensitive Motion Sensor that triggers withing 10ft and at a 120 degree angle.
• Auto delay and restore in dark to save energy
Propel 16 LED Wireless Solar Motion Sensor Light
• Solar panel: 0.55W, 17% efficiency
• Li-ion battery: 3.7V 800mAh
• Switch inside for saving power during shipment
• LED: 16LED
• Lumens: 100lm
• LED span life: 50,000 hours
• Solar charging time: 8 hours
• Lighting mode: Dark/DIM/bright; DIM: weak lighting for saving power; Bright: motion activate for lighting
• Auto identify day or night
• Safety Features: Over charging, over discharging, over current, short circuit
• Li-ion battery span life: 500 circles

Hybrid solar inverter 5000w communication RS485 MC4 connector waterproof IP65 on/off grid solar inverter automatic . DC /AC solar system with battery back up

Hybrid solar inverter 5000w communication RS485 MC4 connector waterproof IP65 on/off grid solar inverter automatic . DC /AC solar system with battery back up

ONE TAIWAN ONE CHINA

Today,The place of taiwan are held in 2016 Taiwan leader election,the result will be published around on 22:00(Beijing time)16th,Jan, 2016 .


Three candidates：chuyu song、 lilun zhu、  yingwen cai、

Anyway,the Principle will not change: ONE TAIWAN   ONE CHINA.

HIGH-EFFICIENCY HYBRID / OFF-GRID SOLAR INVERTER WITH 50A CHARGER (PWM) SERIES 1000VA/2000VA/3000VA/4000VA/5000VA

HIGH-EFFICIENCY HYBRID / OFF-GRID

SOLAR INVERTER WITH 50A CHARGER (PWM) SERIES

1000VA/2000VA/3000VA/4000VA/5000VA

FEATURES
(1) Pure sine wave inverter

(2) Parallel operation with up to 6 units only available for 4000VA/5000VA

(3) Wide input voltage range mode yet safe for PC and other electronics

(4) Selectable input voltage range for home appliances and personal computers

(5) Configurable AC/Solar input priority via LCD setting

(6) Ultra-wide input voltage range mode for home appliances

（7）Selectable charging current suitable for high AH-rating batteries

（8）User-configurable AC/Solar priority logic

（9）Compatible to mains voltage or generator power & Diesel generator compatible

（10）Auto restart once AC has recovered

（11）Overload and short circuit protection

（12) Smart battery charger design for optimized battery performance

(13) Cold start function

(14) Optional Remote Control Panel available

SPECIFICATIONS

MODEL	1000VA	2000VA	3000VA	4000VA	5000VA
Rated Power	1000VA / 800W	2000VA/1600W	3000VA / 2400W	4000VA / 3200W	5000VA / 4000W
INPUT
Voltage	230 VAC
Selectable Voltage Range	170-280 VAC (For Personal Computers)
	90-280 VAC (For Home Appliances)
Frequency Range	50 Hz/60 Hz (Auto sensing)
OUTPUT
AC Voltage Regulation (Batt. Mode)	230VAC ± 15%
Surge Power	2000VA	4000VA	6000VA	8000VA	10000VA
Efficiency (Peak)	93%
Transfer Time	10 ms (For Personal Computers)
	20 ms (For Home Appliances)
Waveform	Pure sine wave
BATTERY
Battery Voltage	12 VDC	24 VDC		48 VDC
Floating Charge Voltage	13.5 VDC	27 VDC		54 VDC
Low Battery Alarm Voltage	10.5 VDC	21 VDC		42 VDC
Shutdown Voltage	10 VDC	20 VDC		40 VDC
Overcharge Protection	15 VDC	30 VDC		60 VDC
Maximum Charge Current	10 A or 20 A	20 A or 30 A		20 A or 30 A
SOLAR CHARGER
Charging Current (ISC)	50A
Suggested operating Voltage Range	15~30VDC	30~60 VDC		60~90 VDC
Maximum PV Array Open Circuit Voltage (VOC)	75 VDC			125 VDC
Standby Power Consumption	1W	2W		2W
PHYSICAL
Dimension (D X W X H)	95 x 250 x 330mm	100 x 272 x 367mm		110 x 300 x 455mm
Net Weight	4kgs	4.5kgs	6.8kgs	7.5kgs	8.5kgs
OPERATING ENVIRONMENT
Humidity	5% to 95% Relative Humidity(Non-condensing)
Operating Temperature	0°C - 55°C
Storage Temperature	-15°C - 60°C

40w waterproof IP65 solar street 60 LED lights hidden camera motion/timer sensor with remote controller full/dim power used for Urban Construction, Government projects

40w waterproof IP65 solar street 60 LED lights hidden camera motion/timer sensor with remote controller full/dim power used for Urban Construction, Government projects


Light Source: LED
Item Type: Street Lights
LED Light Source: Philips
Input Voltage(V): DC12
Lamp Power(W): 20
Lamp Luminous Flux(lm): 3450
Lamp Luminous Efficiency(lm/w): 115
CRI (Ra>): 85
Color Temperature(CCT): Warm White
Working Temperature(℃): -40 - +50
Working Lifetime(Hour): 50000
Lamp Body Material: Aluminum
IP Rating: IP65
Certification: CCC, CE, FCC, LVD, RoHS, UL
Warranty(Year): 3
Place of Origin: Guangdong, China (Mainland)
Brand Name: ACR
Product Name: solar light with hidden camera
Mounting height: 7-8m
Materia: Die-cast aluminium alloy
Service: OEM/ODM
Product Size: 920*330*140mm
Solar Panel: monocrystalline silicon
Solar cel: Poly crystalline
Max power of solar panel: 18V  60w
sensor: motion sensor/ time sensor
Lifetime of battery: 5 years

Components:
    -High efficient solar panel (Built-into the Fixture);
    -Li-Fe battery (Built-into the Fixture);
    -LED Lamp (Built-into the Fixture);
    -MPPT controller (Built-into the Fixture);
    -PIR motion sensor (Built-into the Fixture/Box);
    -Bracket (For Mounting)

FEATURES:

Fully self-contained solar light with more flexibility when mounting.
     -Easy installation. No wiring necessary.

     -Separante panel and light head allows more flexibility in placing fittings.
 Brighter light when you need it.

     -Built-in infra-red motion sensor regulates light output automatically.

     -Changes from dim mode(30%) to bright mode(100%) upon motion detection.

     -Light sensor restricts operation during daylight to save battery power.
Built tough for tough conditions

     -Superbright 30W LED light and powerful 60W solar panel suit many commercial&industrial applications.
Rustproof, dustproof and waterproof

     -Rated IP65 for all outdoor applications
Zero running cost

    -Fully solar powered.

    -Lithium ion battery prolongs life and protects the environment.
